Axial Seal Secondary Air Filter Element | Fleetguard AF25503
Fleetguard® secondary safety air filter featuring an axial gasket designed to secure a tight, leak-free seal and prevent airborne contaminants from reaching the combustion chamber during primary filter servicing. Technical dimensions: height 283 mm, outer diameter 93 mm (max 94 mm), inner diameters 61.5 mm / 16.5 mm. Engineered for agricultural tractors and equipment including SAME (Explorer, Argon, Solar, Frutteto, Centauro series), Fiatagri / New Holland (66, 76, 86 series), AGCO, and Lamborghini. Direct cross-reference for OEM numbers SAME 2.4249.340.2 / 2.4249.390.2 and Fiatagri 1930442, designed to pair with primary filter AF25502K.
Fits Same Minitaurus 60, Centauro 70 (+4) and 4 more brands · 10 models · See all ↓
AF25503
- Fast and tracked deliveriesthroughout Europe
- Easy returnswithin 14 days
- Secure paymentPayPal & cards
Genuine Fleetguard® (AF25503) secondary safety air filter (Inner). Cylindrical cartridge featuring axial seal technology, a height of 284 mm, and a maximum outer diameter of 94 mm. Designed to ensure a proper seal and prevent air leaks during primary filter maintenance.
Technical data and specifications
| Manufacturer Code | AF25503 |
| Filter Type | Secondary Air Filter (Safety / Inner Element) |
| Sealing Style | Axial Seal |
| Height / Length (H) | 284.00 mm (11.18 / 11.10 in) - Approx. 283 mm |
| Largest Outer Diameter (OD) | 94.00 mm (3.70 in) / [A: 93 mm] |
| Inner Dimensions (B / C / A1) | B: 16.5 mm | C: 61.5 mm | A1: 16.5 mm |
| Key OE Cross References | SAME: 2.4249.340.2, 2.4249.390.2 | FIATAGRI: 1930442 | NEW HOLLAND: NP1930442 | AGCO: 2270881, 72270881 | CATERPILLAR: 3I1417 |
Product Description
The Fleetguard AF25503 secondary air filter acts as the ultimate line of defense for the combustion chamber in mid-power agricultural tractors. Engineered to pair seamlessly with the primary outer filter (such as the corresponding AF25502K), this safety element serves a dual purpose: providing temporary protective barrier shielding during main filter servicing in dusty environments, and trapping fine contaminants in case of outer element structural failure. The reliable axial seal design prevents any unfiltered air bypass, maintaining long-term engine health.
Key Macro-Applications
Inner safety air filter highly compatible with the following tractor brands and series: SAME (Tractors): Argon (50, 60), Explorer (Standard Series, II, II Special, C, T), Frutteto (60, 60 II, 75), Solar (50, 55 C, 60), Minitaurus 60 (Frutteto / Synchro), Centauro 70, Centurion 75, Aster 60, Vigneron (62, 70, 75), Mercury 85, Row Crop 85. FIATAGRI / NEW HOLLAND (Tractors): 76 Series (45-76, 55-76, 55-76V, 55-76DT), 66 Series (60-66F, 70-66F), 86 Series (55-86 F, 60-86 F, 70-86, 72-86 LP). AGCO: 4650, 5650, 5670, 5680, 6670 Series. LAMBORGHINI: Compatible models sharing equivalent engine specifications (660DT, 674-70).
Compatibility 10 models
Same 6 models
- Minitaurus 60
- Centauro 70
- Centurion 75
- Aster 60
- Mercury 85
- Row Crop 85
Argon, Explorer, Frutteto, Solar, Vigneron
New Holland · Serie 76
New Holland · Serie 66
New Holland · Serie 86
AGCO · Serie 4650
AGCO 4 models
- 5650
- 5670
- 5680
- 6670
Other notes
SDF: Filtro di sicurezza interno altamente compatibile con i seguenti marchi e serie di trattori:
Lamborghini: Modelli compatibili con motorizzazioni equivalenti (660DT, 674-70)
No model with this name in the list.
Can't find your tractor? Send us the model and serial number: we will check. Check with us
Product sheet
| Code | AF25503 Quote it when you write to us: we answer faster. |
|---|---|
| Brand | Fleetguard |
| Category | SDF (Air Filters) |
| Weight | 0,3 Kg |
Delivery times
They depend on where the product is. If you see the «Standard» and «Urgent» buttons on the page, the item is ordered directly from the manufacturer and you choose the speed.
The product is in our warehouse and ships right away: delivery takes 24/48 working hours from shipment. You can also collect it from us.
Ordered from the manufacturer with standard logistics, at the listed price.
