COD.P770398 Donaldson

Secondary Safety Air Filter Element | Donaldson P770398

Genuine Donaldson secondary safety air filter. Engineered to act as a crucial backup, protecting the engine from dust and contaminants during primary filter service or in case of primary element damage. Technical dimensions: outer diameter 92.46 mm, inner diameter 61 mm, length 282.96 mm. Widely compatible with agricultural equipment including SAME (Explorer, Argon, Solar, Frutteto, Centauro series), Lamborghini (Crono), Hürlimann, Agrifull, and AGCO. Direct replacement for OEM part numbers SDF 2.4249.340.2 / 2.4249.390.2, Fiat / New Holland 1930442, and AGCO 72270881.

Key facts

Fits Hürlimann Series 361 and 5 more brands · 12 models · See all ↓

Original part numbers
  • P770398
Out of Stock
€44.00
Tax not applicable
Coupon −2% first order
With the coupon you pay 43,12 € instead of 44,00 € · you save 0,88 €
On order · Processable in approximately 2-3 working days

Processable in approximately 2-3 working days
  • Fast and tracked deliveriesthroughout Europe
  • Easy returnswithin 14 days
  • Secure paymentPayPal & cards
Not sure it is the right part? Write to us with your machine code or model

Genuine Donaldson (P770398) secondary safety air filter (Inner). Round cylindrical element featuring a height of 282.96 mm, a maximum outer diameter of 92.46 mm, and a minor diameter of 50.04 mm. Designed to act as an absolute backup barrier and safeguard the engine during primary filter maintenance.

Technical data and specifications

Manufacturer CodeP770398
Filter Type / StyleSafety Filter (Inner) / Round
Length282.96 mm (11.14 in)
Outer Diameter92.46 mm (3.64 in)
Inner Diameter61.00 mm (2.40 in)
Minor Outer Diameter (DO minore)50.04 mm (1.97 in)
Efficiency Test StandardISO 5011
Key OE Interchange CodesSAME / DEUTZ-FAHR: 2.4249.340.2, 2.4249.390.2 | FIATAGRI / CASE IH / NEW HOLLAND: 1930442, NP1930442 | AGCO: 72270881 | CATERPILLAR: 3I1417

Key Macro-Applications

Highly compatible inner safety filter certified for the following brands and series: Agricultural Tractors & Machinery: SAME: Argon (50, 60), Explorer (55, 60, 70, 75C Ergomatic), Frutteto (60 DT), Solar 50, Aster 60, Corsaro 70, Mercury 85, Vigneron (60, 75), and 60 II series. AGCO: 4000 Series (4650, 4660), 5000 Series (5650), 6000 Series (6045, 6065, 6670). AGRIFULL: 50 Series (50, 50DT, 55CF, 55CV, 55DT, 55DTT). HÜRLIMANN TRACTORS: 361 Series (F, V, XF), 468, 468.4, H 305 XE, H 306 XE, H 358 Prestige, H 358.4, H 468.4. LAMBORGHINI: Crono 564-60DTA.

Why choose Donaldson

  • Donaldson safety filters perform crucial functions to protect the engine block in heavy-duty environments:
  • Backup filtration: They function as a reserve filter, blocking debris in case of damage or improper installation of the main primary filter.
  • Maintenance protection: They prevent ambient contaminants from entering the clean side of the air intake system while servicing or removing the primary filter.
  • Early alerting: They are engineered to plug rapidly if contamination bypasses the primary cartridge, reducing performance to immediately alert operators to a system issue.
  • Service interval: It is recommended to replace safety filters every three primary filter changes, unless a primary filter breakdown has occurred.

Compatibility 12 models

Same 4 models

  • Solar 50
  • Aster 60
  • Corsaro 70
  • Mercury 85

Argon, Explorer, Frutteto, Vigneron, e serie 60 II

AGCO · Serie 4000

AGCO · Serie 5000

AGCO · Serie 6000

Agrifull · Serie 50

Hürlimann · Serie 361

Hürlimann 7 models

  • 468
  • 468.4
  • H 305 XE
  • H 306 XE
  • H 358 Prestige
  • H 358.4
  • H 468.4

Lamborghini

  • Crono 564-60DTA

Other notes

SDF: Filtro di sicurezza interno di elevata compatibilità specifico per i seguenti marchi e serie:

Can't find your tractor? Send us the model and serial number: we will check. Check with us

Product sheet

Code P770398 Quote it when you write to us: we answer faster.
BrandDonaldson
CategorySDF (Air Filters)
Weight0,3 Kg
