⚠ Info Immagine: The image is for demonstration purposes only and may not represent the exact appearance of the product.
Premium Fleetguard® Magnum series primary air filter featuring an axial gasket designed to secure a tight seal and block airborne contaminants from reaching the combustion chamber. Delivers 99.95% efficiency (ISO 5011 tested). Dimensions: height 393.7 mm, outer diameter 156 mm, inner diameter 88.5 mm. Highly compatible with agricultural and industrial machinery including SAME (Explorer, Dorado, Silver, Laser, Argon), Lamborghini, Hürlimann, Deutz-Fahr, Massey Ferguson, Case IH, JCB, and Komatsu. Direct replacement for SDF 2.4249.131.0, MANN C16340, and Donaldson P771550, pairing with secondary filter AF4103.
Fits SDF and one more brand
AF4748KGenuine Fleetguard® (AF4748K) outer finned primary air filter element. High-performance cartridge featuring axial seal technology, a height of 393.70 mm, and a maximum outer diameter of 156 mm. Designed to ensure a secure seal and prevent airborne contaminants from reaching the combustion chamber.
| Manufacturer Code | AF4748K |
| Filter Type | Outer Air Cartridge (Primary Element) |
| Sealing Style / Flow Direction | Axial Seal / Outside In (Out to In) |
| Height (H) | 393.700 mm (15.50 in) |
| Largest Outer Diameter (OD) | 156.000 mm (6.14 in) |
| Largest Inner Diameter (ID) | 88.500 mm (3.48 in) |
| Fin Diameter | 199.500 mm (7.85 in) |
| Maximum Service Life Efficiency | 99.95% (ISO 5011 Standard) |
| Flame Retardant Material | No |
The Fleetguard AF4748K primary air filter is a superior-quality component engineered to meet the stringent filtration standards of heavy-duty engines used in agriculture, construction, and earthmoving. Equipped with integrated fins for cyclonic pre-separation of coarse debris, this filter utilizes an axial seal design that eliminates air bypass risks. Compliant with ISO 5011 testing standards, it delivers a maximum service life efficiency of 99.95% with an "outside in" airflow direction, reliably protecting cylinders, valves, and turbochargers against premature wear in harsh dusty environments.
High-compatibility primary air filter specifically engineered for the following brands and sectors: Agricultural Tractors & Machinery: AGCO (6000/7000 Series), SAME (Explorer, Antares, Dorado, Silver, Laser, Frutteto, Argon, Buffalo, Panther), LAMBORGHINI (Agile, Formula, Grand Prix, Premium, R2/R4), HÜRLIMANN (XA, XT, H-Series), DEUTZ-FAHR (Agrolux, Agroplus), MASSEY FERGUSON (3000, 6100, 3300, 3400 Series), LANDINI (Legend), CASE IH (Maxxum). Earthmoving & Excavators: KOMATSU (PC, PW Series), JCB (JS Excavator Series), CATERPILLAR, NEW HOLLAND CONSTRUCTION (LB, 555E/655E Series), POCLAIN. Commercial Vehicles & Buses: BLUE BIRD (All American RE), ASHOK LEYLAND (Freighter / 50 Series), SLANZI, SULLAIR.
SDF: Filtro aria primario ad elevata compatibilità specifico per i seguenti settori e marchi:
Case IH: Trattori e Macchine Agricole
SDF: Escavatori e Movimento Terra, CONSTRUCTION, POCLAIN
SDF: Veicoli Commerciali e Autobus: BLUE BIRD, ASHOK LEYLAND, SLANZI, SULLAIR
No model with this name in the list.
Can't find your tractor? Send us the model and serial number: we will check. Check with us
| Code | AF4748K Quote it when you write to us: we answer faster. |
|---|---|
| Brand | Fleetguard |
| Category | SDF (Air Filters) |
| Weight | 0,5 Kg |
