Konepac Conical Primary Air Filter | Donaldson P770397
Genuine Donaldson Konepac™ conical primary air filter featuring high-efficiency cellulose media (99.9% ISO 5011 tested). Designed to deliver superior filtration and a secure seal in rugged conditions. Technical dimensions: outer diameter 148.08 mm, inner diameter 82 mm, length 315.47 mm. Widely compatible with agricultural tractors including SAME (Explorer, Argon, Frutteto, Solar, Vigneron series), Lamborghini, Hürlimann, Agrifull, and AGCO. Direct cross-reference for SDF 2.4249.340.1 / 2.4249.390.1, Fiat / New Holland 1930443, and AGCO 72270880.
Fits Hürlimann Modelli 361, 468 (+6) and 4 more brands · 12 models · See all ↓
P770397
- Fast and tracked deliveriesthroughout Europe
- Easy returnswithin 14 days
- Secure paymentPayPal & cards
Genuine Donaldson (P770397) primary conical air filter element (Konepac™ Line). High-efficiency cellulose cartridge (99.9%) featuring a conical design, a length of 315.47 mm, and a maximum outer diameter of 148.08 mm. Developed to ensure optimal filtration and a secure seal in compact tractor intake systems.
Technical data and specifications
| Manufacturer Code | P770397 |
| Filter Type / Style | Outer Air Cartridge (Primary) / Conical Konepac™ |
| Length | 315.47 mm (12.42 in) |
| Outer Diameter | 148.08 mm (5.83 in) |
| Inner Diameter | 82.00 mm (3.23 in) |
| Minor Outer Diameter (DO minore) | 112.00 mm (4.41 in) |
| Efficiency / Test Standard | 99.9% / ISO 5011 |
| Filter Media | High-performance Cellulose |
| Key OE Cross References | SAME / DEUTZ-FAHR / HÜRLIMANN: 2.4249.340.1, 2.4249.390.1 | FIATAGRI / CASE IH / NEW HOLLAND: 1930443, NP1930443 | AGCO: 72270880 | CATERPILLAR: 3I1416 |
Product Description
The Donaldson P770397 primary air filter from the Konepac™ line is specifically engineered to optimize space within compact engine compartments while providing an expanded filtration surface area thanks to its conical geometry. Certified to ISO 5011 international standards with a 99.9% efficiency rating, this filter reliably traps fine dust, soil, and environmental debris. Its robust cellulose construction ensures a steady and clean airflow to the engine, safeguarding pistons, cylinders, and valves against premature wear during intensive field operations.
Key Macro-Applications
Specific conical primary air filter compatible with a wide selection of tractors and agricultural machinery: SAME (Tractors): Argon (50, 60), Explorer (55, 60, 70, 75C Ergomatic), Frutteto (60 DT), Solar 50, Aster 60, Corsaro 70, Mercury 85, Vigneron (60, 75), and 60 II series. AGCO: 4000 Series (4650, 4660), 5000 Series (5650), 6000 Series (6065, 6670). AGRIFULL: 50 Series (50, 50DT, 55CF, 55CV, 55DT, 55DTT). HÜRLIMANN TRACTORS: 361 Series (F, V, XF), 468, 468.4, H 305 XE, H 306 XE, H 358 Prestige, H 358.4, H 468.4.
Compatibility 12 models
Same 4 models
- Solar 50
- Aster 60
- Corsaro 70
- Mercury 85
Argon, Explorer, Frutteto, Vigneron, e serie 60 II
AGCO · Serie 4000
AGCO · Serie 5000
AGCO · Serie 6000
Agrifull · Serie 50
Hürlimann 8 models
- Modelli 361
- 468
- 468.4
- H 305 XE
- H 306 XE
- H 358 Prestige
- H 358.4
- H 468.4
Other notes
SDF: Filtro aria primario conico specifico compatibile con un'ampia gamma di trattori e macchinari agricoli:
No model with this name in the list.
Can't find your tractor? Send us the model and serial number: we will check. Check with us
Product sheet
| Code | P770397 Quote it when you write to us: we answer faster. |
|---|---|
| Brand | Donaldson |
| Category | SDF (Air Filters) |
| Weight | 1,9 Kg |
