COD.AF25502K Fleetguard

Axial Seal Primary Air Filter Element | Fleetguard AF25502K

Premium Fleetguard® primary air filter featuring an axial gasket designed to secure a reliable, leak-free seal and block airborne contaminants. Delivers 99.8% filtration efficiency (ISO 5011 tested) with outside-in airflow. Dimensions: length 327 mm, outer diameter 149 mm, inner diameter 80.5 mm. Engineered for agricultural tractors and equipment including SAME (Explorer, Argon, Solar, Frutteto, Centauro series), Lamborghini, Fiatagri / New Holland (66, 76, 86 series), and AGCO. Direct cross-reference for OEM numbers SAME 2.4249.340.1, Fiatagri 1930443, and New Holland NP1930443.

Key facts

Fits Lamborghini 660DT, 660 F (+4) and 4 more brands · 10 models · See all ↓

Original part numbers
  • AF25502K
Out of Stock
€59.90
Tax not applicable
Coupon −2% first order
With the coupon you pay 58,70 € instead of 59,90 € · you save 1,20 €
On order · Processable in approximately 2-3 working days

Processable in approximately 2-3 working days
  • Fast and tracked deliveriesthroughout Europe
  • Easy returnswithin 14 days
  • Secure paymentPayPal & cards
Not sure it is the right part? Write to us with your machine code or model

Genuine Fleetguard® (AF25502K) outer finned primary air filter element. High-performance cellulose cartridge featuring axial seal technology, a length of 327 mm, and a maximum outer diameter of 149 mm. Designed to ensure an airtight seal and prevent leaks in agricultural tractor intake systems.

Technical data and specifications

Manufacturer CodeAF25502K
Filter TypeOuter Air Cartridge (Primary Element)
Sealing Style / Flow DirectionAxial Seal / Outside In (Out to In)
Height / Length327 mm (12.87 / 12.80 in)
Largest Outer Diameter (OD)149.00 mm (5.87 in)
Smallest Outer Diameter (OD)119.50 mm (4.70 in)
Largest Inner Diameter (ID)80.50 mm (3.17 in)
Fin Diameter159.50 mm (6.28 in)
Media Type / EfficiencyCellulose / 99.8% (ISO 5011 Standard)
Flame Retardant MaterialNo
Key OE Cross ReferencesSAME: 2.4249.340.1, 2.4249.390.1 | FIATAGRI: 1930443 | NEW HOLLAND: NP1930443 | AGCO: 72270880, 2270884

Product Description

The Fleetguard AF25502K primary air filter is engineered to deliver superior-level air filtration for utility tractors and specialized agricultural machinery. Equipped with integrated fins, the filter generates a cyclonic airflow path that pre-separates heavier dust particles before they reach the high-efficiency cellulose media. The axial seal design guarantees a complete enclosure with zero unfiltered air bypass, actively safeguarding the combustion chamber, valves, and cylinders against premature wear in dusty operational environments. Compliant with ISO 5011 standards, it provides a maximum service life efficiency of 99.8%.

Key Macro-Applications

High-compatibility primary air filter specifically engineered for the following tractor brands and models: SAME (Tractors): Argon (50, 60), Explorer (Standard Series, II, II Special, C, T), Frutteto (60, 60 II, 75), Solar (50, 55 C, 60, 60 C), Minitaurus 60 (Synchro / Frutteto), Centauro (70 Export / Special), Centurion 75, Aster 60, Vigneron 62, Special, Export. FIATAGRI / NEW HOLLAND (Tractors): 76 Series (45-76, 55-76, 55-76V, 55-76DT), 66 Series (60-66F, 70-66F), 86 Series (72-86F, 72-86 LP, 55-86 F, 60-86 F, 70-86). LAMBORGHINI (Tractors): 660DT, 660 F (Plus), 674-70 (Sprint, DT), C 554, C 664 (Ergomatic), R 674-70. AGCO: Compatible with tractor series 4660.

Compatibility 10 models

Same 4 models

  • Minitaurus 60
  • Centurion 75
  • Aster 60
  • Vigneron 62

Argon, Explorer, Frutteto, Solar, Centauro, Special, Export

New Holland · Serie 76

New Holland · Serie 66

New Holland · Serie 86

Lamborghini 6 models

  • 660DT
  • 660 F
  • 674-70
  • C 554
  • C 664
  • R 674-70

Other notes

SDF: Filtro primario specifico ad altissima compatibilità per i seguenti marchi e modelli di trattori:

AGCO: Modelli compatibili serie trattori 4660

Can't find your tractor? Send us the model and serial number: we will check. Check with us

Product sheet

Code AF25502K Quote it when you write to us: we answer faster.
BrandFleetguard
CategorySDF (Air Filters)
Weight1,46 Kg
