⚠ Info Immagine: The image is for demonstration purposes only and may not represent the exact appearance of the product.
Axial Seal Primary Air Filter Element | Fleetguard AF25502K
Premium Fleetguard® primary air filter featuring an axial gasket designed to secure a reliable, leak-free seal and block airborne contaminants. Delivers 99.8% filtration efficiency (ISO 5011 tested) with outside-in airflow. Dimensions: length 327 mm, outer diameter 149 mm, inner diameter 80.5 mm. Engineered for agricultural tractors and equipment including SAME (Explorer, Argon, Solar, Frutteto, Centauro series), Lamborghini, Fiatagri / New Holland (66, 76, 86 series), and AGCO. Direct cross-reference for OEM numbers SAME 2.4249.340.1, Fiatagri 1930443, and New Holland NP1930443.
Fits Lamborghini 660DT, 660 F (+4) and 4 more brands · 10 models · See all ↓
AF25502K
- Fast and tracked deliveriesthroughout Europe
- Easy returnswithin 14 days
- Secure paymentPayPal & cards
Genuine Fleetguard® (AF25502K) outer finned primary air filter element. High-performance cellulose cartridge featuring axial seal technology, a length of 327 mm, and a maximum outer diameter of 149 mm. Designed to ensure an airtight seal and prevent leaks in agricultural tractor intake systems.
Technical data and specifications
| Manufacturer Code | AF25502K |
| Filter Type | Outer Air Cartridge (Primary Element) |
| Sealing Style / Flow Direction | Axial Seal / Outside In (Out to In) |
| Height / Length | 327 mm (12.87 / 12.80 in) |
| Largest Outer Diameter (OD) | 149.00 mm (5.87 in) |
| Smallest Outer Diameter (OD) | 119.50 mm (4.70 in) |
| Largest Inner Diameter (ID) | 80.50 mm (3.17 in) |
| Fin Diameter | 159.50 mm (6.28 in) |
| Media Type / Efficiency | Cellulose / 99.8% (ISO 5011 Standard) |
| Flame Retardant Material | No |
| Key OE Cross References | SAME: 2.4249.340.1, 2.4249.390.1 | FIATAGRI: 1930443 | NEW HOLLAND: NP1930443 | AGCO: 72270880, 2270884 |
Product Description
The Fleetguard AF25502K primary air filter is engineered to deliver superior-level air filtration for utility tractors and specialized agricultural machinery. Equipped with integrated fins, the filter generates a cyclonic airflow path that pre-separates heavier dust particles before they reach the high-efficiency cellulose media. The axial seal design guarantees a complete enclosure with zero unfiltered air bypass, actively safeguarding the combustion chamber, valves, and cylinders against premature wear in dusty operational environments. Compliant with ISO 5011 standards, it provides a maximum service life efficiency of 99.8%.
Key Macro-Applications
High-compatibility primary air filter specifically engineered for the following tractor brands and models: SAME (Tractors): Argon (50, 60), Explorer (Standard Series, II, II Special, C, T), Frutteto (60, 60 II, 75), Solar (50, 55 C, 60, 60 C), Minitaurus 60 (Synchro / Frutteto), Centauro (70 Export / Special), Centurion 75, Aster 60, Vigneron 62, Special, Export. FIATAGRI / NEW HOLLAND (Tractors): 76 Series (45-76, 55-76, 55-76V, 55-76DT), 66 Series (60-66F, 70-66F), 86 Series (72-86F, 72-86 LP, 55-86 F, 60-86 F, 70-86). LAMBORGHINI (Tractors): 660DT, 660 F (Plus), 674-70 (Sprint, DT), C 554, C 664 (Ergomatic), R 674-70. AGCO: Compatible with tractor series 4660.
Compatibility 10 models
Same 4 models
- Minitaurus 60
- Centurion 75
- Aster 60
- Vigneron 62
Argon, Explorer, Frutteto, Solar, Centauro, Special, Export
New Holland · Serie 76
New Holland · Serie 66
New Holland · Serie 86
Lamborghini 6 models
- 660DT
- 660 F
- 674-70
- C 554
- C 664
- R 674-70
Other notes
SDF: Filtro primario specifico ad altissima compatibilità per i seguenti marchi e modelli di trattori:
AGCO: Modelli compatibili serie trattori 4660
No model with this name in the list.
Can't find your tractor? Send us the model and serial number: we will check. Check with us
