Cylinder Liner and Piston Kit for Case IH / Steyr - Ø 105 mm (35x88 mm Pin)

Name: Cylinder Liner and Piston Kit for Case IH / Steyr - Ø 105 mm (35x88 mm Pin)
SKU: 38060096
Price: 245 EUR
Availability: OutOfStock

Brand:

Rif.: 38060096

PRODUCT TEMPORARILY OUT OF STOCK

The premium complete cylinder liner and piston assembly (part number 38060096) is an engine overhaul kit for Case IH and Steyr tractors. It features a 105 mm liner and a high-precision 3-ring piston with a 35x88 mm pin, 60 mm combustion chamber diameter, and 21.7 mm chamber depth.

PLEASE NOTE: Delivered without O-rings.

Out of Stock

€245.00 Tax not applicable

Quantity

Add to Compare

Add to Wishlist

Availability: Out of stock

Add to compare Add to wishlist

Security Policies

Secure Shopping. Data protected with encryption. Your privacy is our priority!

Shipping Policies

Fast and reliable shipping. Orders delivered with care. Various options.

Secure Payments

Secure payments! Transactions are protected by encryption. Your security is guaranteed.

Genuine GRANIT complete cylinder liner and piston kit for high-performance agricultural and industrial engines. A professional grade engine overhaul assembly matched with micro-tolerances, engineered to handle heavy thermo-mechanical stress and rebuild proper cylinder compression levels.
Note: Delivery excludes the cylinder liner sealing o-rings.

Product Description

The GRANIT complete cylinder sleeve and piston assembly (Item code 38060096) is a heavy-duty engine rebuild kit developed specifically for the technical overhaul of high-performance diesel engines powering Case IH and Steyr agricultural machinery with MWM builds. The comprehensive kit features a highly durable cylinder sleeve paired with a precision-machined 105 mm piston running a balanced 3-ring layout, engineered to optimize oil film friction and tightly prevent internal gas blow-by. The piston crown features an advanced 60 mm diameter combustion bowl with a depth of 21.7 mm, maximizing the air-fuel mixing swirl and direct injection efficiency to return optimal horsepower output, structural torque, and dependable fuel economy to the rebuilt engine block.

Technical Data and Specifications

Product	Complete Cylinder Liner and Piston Assembly (Engine Overhaul Kit)
Bore (Piston/Liner Ø)	105 mm
Piston Ring Configuration	3 piston rings
Piston Pin Dimensions (Ø x L)	35 mm x 88 mm
Combustion Chamber Bowl Profile	Ø 60 mm \| Depth: 21.7 mm
Brand Compatibility	Case IH / Steyr (International Harvester)
Compatible Tractor Series	• Compact Series: C 64, C 70 • CS Series: CS 68, CS 75, CS 78, CS 86, CS 94 • 900 / 9000 Series: 964, 970, 9078, 9086, 9094 • M 900 / M 9000 Series: M 968, M 975, M 9078, M 9083, M 9086, M 9094
Original References (OEM Ref.)	130100040723 + 130182030705
Total Kit Weight	1.96 kg
Item Code	38060096
