Notched Disc Harrow Blade 610 mm Hexagon 92 mm | OFAS

⚠ Info Immagine: The image is for demonstration purposes only and may not represent the exact appearance of the product.

Notched Disc Harrow Blade 610 mm Hexagon 92 mm | OFAS
Notched Disc Harrow Blade 610 mm Hexagon 92 mm | OFAS
COD.55890 Ofas

Notched Harrow Disc D.610 mm Thickness 5 mm Hex 92 mm

No reviews yet Be the first to review

Notched disc harrow blade made of boron steel (30 MnB5). Diameter 610 mm, thickness 5 mm, concavity 61 mm and hexagonal hole 92 mm. Net weight 10.5 kg.

Key facts
Hurry! only 7 items left in stock.
€74.90
Tax not applicable
Coupon −2% first order
With the coupon you pay 73,40 € instead of 74,90 € · you save 1,50 €
Log in to see the code
In stock · few left in stock

Ready for delivery
Add to Compare
Add to Wishlist
  • Fast and tracked deliveriesthroughout Europe
  • Easy returnswithin 14 days
  • Secure paymentPayPal & cards
Not sure it is the right part? Write to us with your machine code or model

Notched disc harrow blade featuring a 610 mm diameter, 5 mm thickness, and an extra-large 92 mm hexagonal center hole for tillage machinery and disc harrows. Manufactured from heavy-duty 30 MnB 5 Boron steel to ensure extended operating life.

Features and benefits

  • 30 MnB 5 Boron steel construction: delivers high hardness, toughness, and long-lasting resistance against severe soil abrasion
  • Notched profile with 61 mm concavity: offers aggressive cutting action on crop residues and deep clod crushing
  • Extra-large 92 mm hexagonal center hole: ensures a precise fit on heavy-duty hexagonal shafts, evenly distributing torsional load and preventing rotational slippage
  • Lightweight 10.5 kg design: achieves effective soil penetration while reducing mechanical stress on the harrow frame

Technical data and specifications

Outer diameter 610 mm
Thickness 5.0 mm
Concavity 61 mm
Net weight 10.5 kg
Type Notched disc harrow blade
Material Boron steel (30 MnB 5)
Center hole Hexagon 92 mm

Tips

Clean the 92 mm hexagonal shaft thoroughly before assembling the disc to guarantee smooth seating along the gang. Torque the main tie rod to manufacturer specifications to avoid stress concentration or cracking around the hexagonal cutout during field work.

Product sheet

Code 55890 Quote it when you write to us: we answer faster.
BrandOfas
CategoryNotched Disc Blades
Weight10,5 Kg
