Notched Disc Harrow Blade 610 mm Square 33 mm | OFAS

⚠ Info Immagine: The image is for demonstration purposes only and may not represent the exact appearance of the product.

Notched Disc Harrow Blade 610 mm Square 33 mm | OFAS
Notched Disc Harrow Blade 610 mm Square 33 mm | OFAS
COD.57484 Ofas

Notched Harrow Disc D.610 mm Thickness 5 mm Square 33 mm

No reviews yet Be the first to review

Notched disc harrow blade made of boron steel (30 MnB5). Diameter 610 mm, thickness 5 mm, concavity 73 mm and square hole 33 mm. Net weight 10.5 kg. Ref. NARDI SRL 11134138.

Key facts
Out of Stock
€79.90 Tax not applicable
Coupon −2% first order
With the coupon you pay 78,30 € instead of 79,90 € · you save 1,60 €
Log in to see the code
On order · Processable in approximately 2-3 working days

Processable in approximately 2-3 working days
Add to Compare
Add to Wishlist
  • Fast and tracked deliveriesthroughout Europe
  • Easy returnswithin 14 days
  • Secure paymentPayPal & cards
Not sure it is the right part? Write to us with your machine code or model

Notched disc harrow blade 11134138 for Nardi tillage machinery. Manufactured from heavy-duty 30 MnB 5 Boron steel with a 610 mm diameter, 5 mm thickness, and a 33 mm square center hole.

Features and benefits

  • 30 MnB 5 Boron steel construction: delivers high hardness and long-lasting resistance against severe soil abrasion
  • Notched profile with 73 mm concavity: offers aggressive cutting, effective residue management, and deep soil penetration
  • 33 mm square center hole: provides a positive fit on the gang shaft, eliminating rotational slippage
  • Precision replacement for Nardi harrows: matches original engineering specifications for easy replacement on harrow gangs

Technical data and specifications

Outer diameter 610 mm
Thickness 5 mm
Concavity 73 mm
Net weight 10.5 kg
Code 11134138
Equivalent codes 11134138
Type Notched disc harrow blade
Material Boron steel (30 MnB 5)
Center hole Square 33 mm

Compatibility

Nardi 11134138

Tips

Clean the 33 mm square shaft thoroughly before assembling the disc to guarantee smooth seating along the gang. Torque the main tie rod to manufacturer specifications to avoid stress cracking around the square cutout when working in stony field conditions.

Product sheet

Code 57484 Quote it when you write to us: we answer faster.
BrandOfas
CategoryNotched Disc Blades
Weight10,5 Kg
