Notched Disc Harrow Blade 660 mm Square 41 mm | OFAS

⚠ Info Immagine: The image is for demonstration purposes only and may not represent the exact appearance of the product.

Notched Disc Harrow Blade 660 mm Square 41 mm | OFAS
Notched Disc Harrow Blade 660 mm Square 41 mm | OFAS
COD.56391 Ofas

Notched Harrow Disc D.660 mm Thickness 6 mm Square 41 mm

No reviews yet Be the first to review

Notched disc harrow blade made of boron steel (30 MnB5). Diameter 660 mm, thickness 6 mm, concavity 100 mm and square hole 41 mm. Net weight 15.5 kg. Ref. AGRIWAY 3362416606.

Key facts
Original part numbers
  • 3362416606
Hurry! only 10 items left in stock.
€86.90
Tax not applicable
Coupon −2% first order
With the coupon you pay 85,16 € instead of 86,90 € · you save 1,74 €
Log in to see the code
In stock · plenty available

Ready for delivery
Add to Compare
Add to Wishlist
  • Fast and tracked deliveriesthroughout Europe
  • Easy returnswithin 14 days
  • Secure paymentPayPal & cards
Not sure it is the right part? Write to us with your machine code or model

Notched disc harrow blade 3362416606 for Agriway tillage machinery. Manufactured from heavy-duty 30 MnB 5 Boron steel featuring a large 660 mm diameter, heavy-duty 6 mm thickness, and a 41 mm square center hole.

Features and benefits

  • 30 MnB 5 Boron steel construction: delivers high hardness, toughness, and long-lasting resistance against severe soil abrasion
  • Heavy-duty 6 mm thickness with deep 100 mm concavity: provides robust structural strength to withstand heavy impacts while deeply penetrating compacted soil
  • Notched edge profile: offers aggressive cutting action on crop residues and superior clod crushing performance
  • 41 mm square center hole: provides a positive fit on the gang shaft, eliminating rotational slippage under heavy draft loads

Technical data and specifications

Outer diameter 660 mm
Thickness 6 mm
Concavity 100 mm
Net weight 15.5 kg
Code 3362416606
Equivalent codes 3362416606
Type Notched disc harrow blade
Material Boron steel (30 MnB 5)
Center hole Square 41 mm

Compatibility

Agriway 3362416606

Tips

Clean the 41 mm square shaft thoroughly before assembling the disc to guarantee smooth seating along the gang. Torque the main tie rod to manufacturer specifications to avoid stress concentration or cracking around the square cutout when working in tough field conditions.

Compatibility

Agriway: 3362416606
