⚠ Info Immagine: The image is for demonstration purposes only and may not represent the exact appearance of the product.
Notched disc harrow blade made of boron steel (30 MnB5). Diameter 610 mm, thickness 6 mm, concavity 84 mm and square hole 41 mm. Net weight 12.7 kg.
Notched disc harrow blade with a 610 mm diameter, heavy-duty 6 mm thickness, and a 41 mm square center hole for tillage machinery and disc harrows. Manufactured from heavy-duty 30 MnB 5 Boron steel to ensure extended operating life.
| Outer diameter | 610 mm |
| Thickness | 6 mm |
| Concavity | 84 mm |
| Net weight | 12.7 kg |
| Type | Notched disc harrow blade |
| Material | Boron steel (30 MnB 5) |
| Center hole | Square 41 mm |
Clean the 41 mm square shaft thoroughly before assembling the disc to guarantee smooth seating along the gang. Torque the main tie rod to manufacturer specifications to avoid stress concentration or cracking around the square cutout when working in tough field conditions.
| Code | 56393 Quote it when you write to us: we answer faster. |
|---|---|
| Brand | Ofas |
| Category | Notched Disc Blades |
| Weight | 12,7 Kg |
