PTO wood chipper Ø 60 mm TRICARD

PTO tractor wood chipper TRICARD by Ceccato Olindo for three-point hitch mounting, designed for domestic and semi-professional shredding of branched green waste up to 6 cm in diameter. Features a belt-driven multiplier system between the PTO shaft and the rotor equipped with 8 internal shredding knives.

Features and benefits

• Safety belt drive transmission: absorbs cutting shock loads to prevent direct impact and stress on the tractor PTO shaft
• High-reduction cutting rotor: combines 2 main blades, 2 counter-blades, and 8 shredding knives for rapid branch volume reduction
• Integrated three-point hitch: enables easy lifting and transport of the chipper directly via the tractor hydraulic linkage
• Anti-clogging specialized wheels: made from a unique rubber compound engineered to prevent stones from sticking during ground movement
• 360 x 360 mm loading hopper: allows easy insertion of bulky branches and pruning debris up to 6 cm in diameter
• Provision for optional sieves: accepts refining screens to calibrate and reduce final woodchip size

Technical data and specifications

Tips

Always work with the PTO driveshaft properly aligned and do not exceed the maximum 540 rpm PTO speed to prevent premature wear on rotor bearings. Before unhitching the machine from the tractor linkage after work, let the chipper run empty for a few seconds to completely clear the shredding chamber of leaves and damp woodchips.
