Standard R10 series driveline shaft with a lemon-shaped profile. It features a length of 1010 mm and comes with usage and maintenance instructions. The transmissible power is up to 21 hp (15 kW) at 540 rpm and up to 32 hp (24 kW) at 1000 rpm. The net weight is 8.70 kg.
Security Policies
Secure Shopping. Data protected with encryption. Your privacy is our priority!
Shipping Policies
Fast and reliable shipping. Orders delivered with care. Various options.
Secure Payments
Secure payments! Transactions are protected by encryption. Your security is guaranteed.
Code: PTOR10LPPCS1PPCS11010.
Length (Lz): 1010 mm.
Profile A/B: 1 3/8" 6 teeth.
Cross dimensions: 22 x 54 mm.
Profile tube: 3.4 x 30.8 x 23.7 mm (inner) / 2.8 x 39.1 x 30.0 mm (outer).
Net weight: 8.70 kg.
Clutch: Without.
Power at 540 rpm: 21 hp / 15 kW.
Torque at 540 rpm: 273 Nm.
Power at 1000 rpm: 32 hp / 24 kW.
Torque at 1000 rpm: 228 Nm.
Comparative models: F21, AW10, AW10S, W2100.
Usage and maintenance instructions are included.
EAN Code: 4059139528936
