Cabin Fresh Air Filter | UFI Filters 53.485.00
UFI Filters 53.485.00 cabin fresh air filter (OEM equivalent John Deere RE198488, RE73220, JCB 334/S0776, MANN CU3939, and Fleetguard AF27954). Engineered to filter incoming outside air, capturing dust, pollen, and airborne particles to provide a clean, safe, and comfortable working environment inside the cab. Technical specs: length (A) 388 mm, width (B) 122 mm, height (H) 30 mm, net weight 137 g. Fully compatible with a vast lineup of John Deere equipment, including 5000 Series (5E, 5M, 5R), 6000 Series (6MC, 6RC, 6D, 6E, 6B) tractors, combines (S700 series, C440), forestry machinery (1010E/G, 1210E/G, 1470E/G, 1910E/G), construction equipment (210G, 210K, 210L, 320P), and JCB machinery. Premium choice for routine HVAC system servicing.
Fits John Deere Series 5000: 5045E and 6000: 6B-1404 (+1) · 94 models · See all ↓
53.485.00RE198488RE73220334/S0776CU3939AF27954E5920LISC90114P956136PA30086WP10160
Want to be notified?
Leave your email: we will notify you as soon as it is back in stock.
- Fast and tracked deliveriesthroughout Europe
- Easy returnswithin 14 days
- Secure paymentPayPal & cards
UFI FILTERS 53.485.00 cabin air filter. High-quality filter element designed to trap dust, pollen, and impurities, ensuring fresh and healthy air inside the cabin. Essential for operator comfort and for protecting the air conditioning system of agricultural and forestry machinery.
Technical data and specifications
| Manufacturer Code | 53.485.00 |
| Brand | UFI FILTERS |
| Filter Type | Cabin Air Filter |
| Dimensions (A x B x H) | 388 x 122 x 30 mm |
| Weight (Net / With Box) | 137 g / 202 g |
| Packaging Data | Box: 35 x 180 x 400 mm (Pallet: 260 pcs) |
| Main Cross References & OE | JOHN DEERE: RE198488, RE73220 | JCB: 334/S0776 | MANN: CU3939 | FLEETGUARD: AF27954 | HENGST: E5920LI | HIFI: SC90114 | DONALDSON: P956136 | BALDWIN: PA30086 | WIX: WP10160 |
Compatibility
| Highly compatible cabin filter for a vast range of John Deere machinery: | |
| 5000 Series: 5045E, 5050E, 5055E, 5058E, 5060E, 5065E/M, 5067E, 5070E/M, 5075E/M, 5076E, 5078E, 5080E/M/R, 5082E, 5083E, 5085E/M, 5090E/EH/M/R, 5093E, 5095M/MH, 5100E/M/MH/R, 5101E, 5105M/MH, 5115M/ML/R/RH, 5120M, 5125M/R, 5130M, 5220, 5225, 5320, 5325, 5420, 5425, 5520, 5525 (including HC versions), 5603, 5620, 5625, 5720, 5725, 5820 | |
| 6000 Series: 6B-1404, 6BH 110, 6E-1004, 6E-1204/P, 6E-1404P/PL, 6E-1504L/PL, 6090 MC/RC, 6095 MC/RC/B, 6100 MC/RC/D/E, 6105 MC/RC/D/E/EH, 6110 MC/RC/B/D/E, 6115 MC/RC/D/E, 6120B/E/EH, 6125D/E, 6130D/E, 6135B/E, 6140B/D/E, 6150B, 6403 (incl. HC), 6603, 6803 | |
| Combines and Harvesters | C2 400, C440, S4 300, S4 400, S5 300, S5 400, S430, S440, S760, S770, S780, S790, W2 400, W200M, W235M, W260M |
| Forestry / Construction Machinery | 210 G/P/K/L/LJ (incl. EP), 320 P, 332M, 340M, 810E, 910G, 1010E/G, 1070E/G, 1110E/G, 1170E/G, 1210E/G, 1270E/G/H, 1354, 1404, 1470E/G/H, 1510E/G, 1610G, 1910E/G, 2010H, 2510H, 3800 |
Why choose UFI Filter
- Comfort and Safety: Ensures a clean work environment, reducing operator fatigue and preventing respiratory problems and allergies.
- A/C System Efficiency: Maintains proper airflow in the A/C system, preventing dust accumulation that could cause overheating and breakdowns.
- Absolute Reliability: UFI Filters is a leader in filtration, providing high-efficiency filter media that comply with OEM standards.
- High Compatibility: Perfectly replaces dozens of original codes (such as John Deere RE198488) and major aftermarket brands.
Compatibility 94 models
John Deere · Serie 5000: 5045E
John Deere 38 models
- 5050E
- 5055E
- 5058E
- 5060E
- 5065E/M
- 5067E
- 5070E/M
- 5075E/M
- 5076E
- 5078E
- 5080E/M/R
- 5082E
- 5083E
- 5085E/M
- 5090E/EH/M/R
- 5093E
- 5095M/MH
- 5100E/M/MH/R
- 5101E
- 5105M/MH
- 5115M/ML/R/RH
- 5120M
- 5125M/R
- 5130M
- 5220
- 5225
- 5320
- 5325
- 5420
- 5425
- 5520
- 5525
- 5603
- 5620
- 5625
- 5720
- 5725
- 5820
John Deere · Serie 6000: 6B-1404
John Deere 20 models
- 6BH 110
- 6E-1004
- 6E-1204/P
- 6E-1404P/PL
- 6E-1504L/PL
- 6090 MC/RC
- 6095 MC/RC/B
- 6100 MC/RC/D/E
- 6105 MC/RC/D/E/EH
- 6110 MC/RC/B/D/E
- 6115 MC/RC/D/E
- 6120B/E/EH
- 6125D/E
- 6130D/E
- 6135B/E
- 6140B/D/E
- 6150B
- 6403
- 6603
- 6803
John Deere 15 models
- C440
- S4 300
- S4 400
- S5 300
- S5 400
- S430
- S440
- S760
- S770
- S780
- S790
- W2 400
- W200M
- W235M
- W260M
Mietitrebbie e Macchine da Raccolta: C2 400
John Deere · Macchine Forestali / Movimento Terra 21 models
- 210 G/P/K/L/LJ
- 320 P
- 332M
- 340M
- 810E
- 910G
- 1010E/G
- 1070E/G
- 1110E/G
- 1170E/G
- 1210E/G
- 1270E/G/H
- 1354
- 1404
- 1470E/G/H
- 1510E/G
- 1610G
- 1910E/G
- 2010H
- 2510H
- 3800
Other notes
John Deere: Filtro cabina ad altissima compatibilità per una vasta gamma di mezzi John Deere:
No model with this name in the list.
Can't find your tractor? Send us the model and serial number: we will check. Check with us
Product sheet
| Code | 53.485.00 Quote it when you write to us: we answer faster. |
|---|---|
| Brand | UFI Filter |
| Category | John Deere (Air Filters) |
| Weight | 0,2 Kg |
