⚠ Info Immagine: The image is for demonstration purposes only and may not represent the exact appearance of the product.
Premium Fleetguard® primary air filter featuring Direct Flow technology, engineered for superior engine protection with a compact profile. It provides a maximum efficiency of 99.95% (ISO 5011 tested) and a nominal flow rate of 8 m³/min with outside-in airflow direction. Dimensions: height 344.5 mm, outer diameter 190 mm, inner diameter 95 mm. Designed for Fendt Farmer (307, 308, 309, 310, 311 Turbo) and Favorit (509C, 510C, 511C) series tractors with MWM TD226B engines. Direct replacement for OEM AGCO H311200090100.
Fits Fendt 307 Turbo, 308 Turbo (+6) · 8 models · See all ↓
AF26175Genuine Fleetguard® (AF26175) outer primary air filter element. Developed with advanced reduced-profile Direct Flow technology for superior engine protection and a significant reduction in maintenance costs. Height of 344.5 mm.
| Manufacturer Code | AF26175 |
| Filter Type | Outer Air Cartridge (Primary - Direct Flow) |
| Height (H) | 344.50 mm (13.56 in) |
| Largest Outer Diameter (OD) | 190.00 mm (7.48 in) |
| Largest Inner Diameter (ID) | 95.00 mm (3.74 in) |
| Nominal Flow Rate | 8.00 m³/min (CU. m/m) |
| Flow Direction | Outside In (Out to In) |
| Maximum Service Life Efficiency | 99.95% |
| Efficiency Test Standard | ISO 5011 |
| Flame Retardant Material | No |
| High-performance primary air filter specific for the following FENDT tractor models (years 1993 →): | |
| Fendt Farmer (300 Turbo Series) | 307 Turbo (TD226 Engine), 308 Turbo (TD226B-4 Engine), 309 Turbo (TD226B-4 Engine), 310 Turbo (TD226B-4 Engine), 311 Turbo (TD226.B6 Engine) |
| Fendt Favorit (500 C Series) | 509C (TD226B-4 Engine), 510C (TD226B-4 Engine), 511C (TD226B-6 Engine) |
The Fleetguard® AF26175 Direct Flow primary filter cartridge represents a technological evolution in air filtration systems for Fendt Farmer and Favorit tractors. Compared to bulky conventional systems, this space-saving design minimizes the application footprint while maintaining unmatched protection parameters: it features an outstanding 99.95% maximum service life efficiency certified to ISO 5011 international standards. With a nominal flow rate of 8.00 m³/min and an "out to in" flow direction, it supplies ultra-pure air to MWM/Deutz TD226B engines, actively preventing premature wear on internal components even during the most demanding and dusty field operations.
Fendt: Filtro primario specifico ad alte prestazioni installato sui seguenti modelli di trattori FENDT (anno 1993 →):
No model with this name in the list.
Can't find your tractor? Send us the model and serial number: we will check. Check with us
| Code | AF26175 Quote it when you write to us: we answer faster. |
|---|---|
| Brand | Fleetguard |
| Category | AGCO (Air Filters) |
| Weight | 1,7 Kg |
