Secondary Air Filter MANN-FILTER CF 22 269 | Agrokron

⚠ Info Immagine: The image is for demonstration purposes only and may not represent the exact appearance of the product.

Secondary Air Filter MANN-FILTER CF 22 269 | Agrokron
COD.CF 22 269 MANN-FILTER

Secondary Safety Air Filter Element | MANN-FILTER CF 22 269

No reviews yet Be the first to review

Premium secondary safety air filter element (inner type) manufactured by MANN-FILTER. It acts as the final protective barrier for the combustion chamber against abrasive contaminants. Dimensions: height 436 mm, outer diameter 220 mm, inner diameter 180 mm / 22 mm. Perfectly suited for heavy-duty agricultural and industrial machinery, including AGCO/Massey Ferguson (Gleaner 85/86), Fendt (9460 R with Cat C13 engine), and Volvo CE, Komatsu, Caterpillar, Hitachi, and Case equipment. Directly replaces OEM codes AGCO 72527839, Donaldson P114931, and Fleetguard AF883M.

Key facts

Fits AGCO Series Macchine da Raccolta (Mietitrebbie) and Macchine Movimento Terra e Sollevamento (+2) · See all ↓

Original part numbers
  • 71409553
  • 72527839
  • 6N-6072
  • 4N-9164
  • 3I0225
  • 8C-2238
Out of Stock
€62.00
Tax not applicable
Coupon −2% first order
With the coupon you pay 60,76 € instead of 62,00 € · you save 1,24 €
Log in to see the code
On order · Processable in approximately 2-3 working days

Processable in approximately 2-3 working days
Add to Compare
Add to Wishlist
  • Fast and tracked deliveriesthroughout Europe
  • Easy returnswithin 14 days
  • Secure paymentPayPal & cards
Not sure it is the right part? Write to us with your machine code or model

Genuine MANN-FILTER (CF 22 269) secondary safety air filter (Inner). High-precision protective element featuring a height of 436 mm and an outer diameter of 220 mm, vital for the inner safeguarding of heavy-duty agricultural and industrial engines.

Technical data and specifications

Manufacturer CodeCF 22 269
Filter TypeSecondary Air Cartridge (Safety / Inner Element)
Height (H)436 mm
Outer Diameter / Outer Diameter 1220 mm / 220 mm
Inner Diameter / Inner Diameter 1180 mm / 22 mm
Key OE Interchange CodesAGCO: 71409553, 72527839 | CATERPILLAR: 6N-6072, 4N-9164, 3I0225, 8C-2238 | VOLVO: 4881175, 4881175-6 | IHC / CASE IH: 942 625 C 1 | BOMAG: 5730118 | ASTRA: 45928 | VALTRA: 8360-017749 | ISUZU: 1142152260

Product Description

The MANN-FILTER CF 22 269 secondary safety element is engineered to serve as a critical internal safety barrier within the air intake systems of high-power commercial, industrial, and agricultural machinery. Positioned inside the main primary filter, this inner element guarantees that no fine dust or abrasive airborne particulates can enter the combustion chamber during outer filter replacements or in the event of primary element damage. Built to MANN-FILTER's rigorous original equipment specifications, it ensures an airtight geometric fit to protect the turbocharger and engine components under extreme high-dust environments.

Key Macro-Applications

High-performance safety filter widely compatible with the following brands and industrial groups: Harvesting Machinery (Combines): AGCO (85 Gleaner Combine, 86 Combine), FENDT (9460 R Combine - 9000 Series). Earthmoving & Construction Equipment: VOLVO CONSTRUCTION EQUIPMENT, CATERPILLAR, KOMATSU, HITACHI, LIEBHERR, CASE CONSTRUCTION, DOOSAN, SANY GROUP, LINK-BELT, ORENSTEIN + KOPPEL (O+K), POCLAIN, FURUKAWA-DRESSER, FIAT-KOBELCO. Heavy Tractors & Agricultural Equipment: MASSEY-FERGUSON TRAKTOREN (5200 Series), VERSATILE, STEIGER, BIG BUD, AGCO (A-Series). Commercial Trucks, Buses & Heavy Vehicles: RENAULT TRUCKS (RVI), ASTRA (IVECO GROUP), FODEN, BOMAG. Industrial Engines & Compressors: INGERSOLL-RAND, GARDNER-DENVER.

Compatibility

AGCO · Macchine da Raccolta (Mietitrebbie)

AGCO · Macchine Movimento Terra e Sollevamento

CONSTRUCTION EQUIPMENT, HITACHI, LIEBHERR, CASE CONSTRUCTION, DOOSAN, SANY GROUP, LINK-BELT, ORENSTEIN + KOPPEL, POCLAIN, FURUKAWA-DRESSER, KOBELCO

AGCO · Trattori e Mezzi Agricoli Pesanti

MASSEY-FERGUSON TRAKTOREN, VERSATILE, STEIGER, BIG BUD

AGCO · Motori Industriali e Compressori

INGERSOLL-RAND, GARDNER-DENVER

Other notes

AGCO: Filtro di sicurezza ad alte prestazioni ampiamente compatibile con i seguenti marchi e gruppi industriali:

AGCO: Veicoli Commerciali, Autobus e Mezzi Industriali: TRUCKS, ASTRA, FODEN, BOMAG

Can't find your tractor? Send us the model and serial number: we will check. Check with us

Product sheet

Code CF 22 269 Quote it when you write to us: we answer faster.
BrandMANN-FILTER
CategoryAGCO (Air Filters)
Weight2 Kg
